Resolution

HDMI video input, resolution up to 3840*2160, 30FPS;

It will automatically detect the input video format and automatically adjust to the specified output size and frame rate:

n  3840×2160@30FPS (NV12)

n  2560x1600@60FPS (NV12)

n  2560x1440@60FPS (NV12)

n  2048x1080@60FPS (YUY2, NV12)

n  1920x1200@60FPS (YUY2, NV12)

n  1920x1080@60FPS (YUY2, NV12)

n  1600x1200@60FPS (YUY2, NV12)

n  1280x1024 (YUY2, NV12)

n  1280x720 (YUY2, NV12)

n  1024x768 (YUY2, NV12)

n  960x540 (YUY2, NV12)

n  640x480 (YUY2, NV12)

n  640x360 (YUY2, NV12)

n  480x270 (YUY2, NV12)

Output format

360MB/s USB3.0 transfer bandwidth

Line in/Mic audio input

UVC compatible, YUY2, NV12 output formats

UAC compatible, LPCM output format
